Fire
Floors
The New Zealand Building Code, Clauses C1-C6 require a minimum critical radiant flux (CRF) when tested to ISO 9239-1:2010 of between 1.2 and 4.5 kW/m² and above, depending on the area within the building and the building’s Risk Group. The fire test ISO 9239:1 2010 is only for floor coverings, not wall coverings. Some tests note a CHF which stands for Critical Heat Flux and is and interchangeable term with CRF.
Floor surface materials in the following areas of buildings must meet the performance criteria specified below:
General fire code requirements (floors)
*Minimum critical radiant flux when tested to ISO 9239-1: 2010
| Area of Building | Buildings not protected with an automatic fire sprinkler system* | Buildings protected with an automatic fire sprinkler system* |
|---|---|---|
|
Sleeping areas and exitways in buildings
where care or dentention is provided.
|
4.5 kW/m² | 2.2 kW/m² |
|
Exitways in all other buildings
|
2.2 kW/m² | 2.2 kW/m² |
|
Firecells accommodating more than 50 persons
|
2.2 kW/m² | 1.2 kW/m² |
|
All other occupied spaces except house hold units
|
1.2 kW/m² | 1.2 kW/m² |
Product specific fire code requirements (floors)
*Minimum critical radiant flux when tested to ISO 9239-1:2010
Products
Critical Radiant Flux kW/m²*
-
Forbo Coral Classic 8.9 kW/m² Forbo Coral Duo 11 kW/m² Forbo Coral Brush 10.4 kW/m² Interface Step Repeat - SR999 (GlasBac) 5.3 kW/m² -
Interface GlasBac Nylon Carpet Tiles Various - Refer to Test Reports Interface CushionBacRE Nylon Carpet Tiles Various - Refer to Test Reports Interface CQuestBio Nylon Carpet Tiles Various - Refer to Test Reports Interface CQuestBioX Nylon Carpet Tiles Various - Refer to Test Reports Forbo Tessera Nylon Carpet Tiles Various - Refer to Test Reports -
Forbo Marmoleum Sheet 5.2 kW/m² Forbo Marmoleum Cocoa 8.4 kW/m² Forbo Marmoleum Modular 6.9 kW/m² Forbo Marmoleum Ohmex (ESD) 6.8 kW/m² Forbo Marmoleum Acoustic 8.4 kW/m² -
Forbo Sphera 9.2 kW/m² Forbo Sphera SD EC 9.6 kW/m² -
Forbo Eternal 8.6 kW/m² Forbo Sarlon 15dB 8.6 kW/m² Forbo Sarlon 19dB 8.1 kW/m² Forbo Forbo Sarlon Modul'up 8.1 kW/m² Forbo Colorex EC SD 10.5 kW/m² -
Forbo Surestep & Safestep 8.8 kW/m² -
Interface 4.5mm SoundChoice LVT 9.4 kW/m² Interface 3mm Criterion LVT 10.0 kW/m² Forbo Allura Flex FL5 6.7 kW/m² Forbo Allura Puzzle 8.8 kW/m² -
norament Pastilles 825 5.6 kW/m² norament Arago 9 kW/m² norament Costello 10.6 kW/m² norament Grano 7.7 kW/m² norament Kivo 9.8 kW/m² norament Pado 9.7 kW/m² norament Satura 10.9 kW/m² noraplan Sentica (2mm) 4.6 kW/m² noraplan Signa (2mm) 8.8 kW/m² noraplan Stone (Smooth) 7.7 kW/m² noraplan Uni 10.3 kW/m² noraplan Ultra Grip 8.5 kW/m² -
Forbo Flotex Sheet 9.0 kW/m² Forbo Flotex Tile 8.4 kW/m²
Walls
General fire code requirements (walls)
*Performance determined under conditions described in ISO 9705:1993
| Area of building | Buildings not protected with an automatic fire sprinkler system* | Buildings protected with an automatic fire sprinkler system* |
|---|---|---|
|
Wall/ceiling materials in sleeping areas where care or detention is provided
|
Material Group Number 1-S | Material Group Number 1 or 2 |
|
Wall/ceiling materials in exitways
|
Material Group Number 1-S | Material Group Number 1 or 2 |
|
Wall/ceiling materials in all occupied spaces in importance level 4 buildings
|
Material Group Number 1-S | Material Group Number 1 or 2 |
|
Internal surfaces of ducts for HVAC systems
|
Material Group Number 1-S | Material Group Number 1 or 2 |
|
Ceiling materials in crowd and sleeping uses except household units and where care or detention is provided
|
Material Group Number 1-S or 2-S | Material Group Number 1 or 2 or 3 |
|
Wall materials in crowd and sleeping uses except household units and where care or detention is provided
|
Material Group Number 1-S or 2-S | Material Group Number 1 or 2 |
|
Wall/ceiling materials in occupied spaces in all other locations in buildings, including household units
|
Material Group Number 1, 2 or 3 | Material Group Number 1 or 2 |
|
External surfaces of ducts for HVAC systems
|
Material Group Number 1, 2 or 3 | Material Group Number 1 or 2 |
|
Acoustic treatment and pipe insulation within airhandling plenums in sleeping uses
|
Material Group Number 1, 2 or 3 | Material Group Number 1 or 2 |
Product specific fire code requirements (walls)
*ISO 9705, ISO 5660 & EN13501
Products
Material group*
-
Onyx+ Group 1 Onyx Impact Group 1s -
Sphera Group 3 Eternal Group 3 Step Safety Group 3 -
Marmoleum Sheet Group 3 Bulletin Board (Pinboard Linoleum) Group 3 Desktop (Furniture Linoleum) Group 3 -
Flotex Sheet Group 3
